Introducing the HIKMICRO Condor LRF

Key Features:

• Cutting-Edge Sensor: The Condor LRF features a <20mK NETD sensor, offering powerful imaging capabilities even in challenging weather conditions.
• Long-Range Accuracy: Equipped with a 1000m laser rangefinder, accurate to +-1m, the Condor ensures precise distance measurement for stalking or observing.
• Rugged and Compact Design: Built with a rugged magnesium alloy housing and boasting an IP67 rating, the Condor is tough enough to withstand outdoor adventures while remaining lightweight and compact for easy portability.
• High-Resolution Display: With a 384 × 288 @ 12 um infrared detector and a 1024 × 768 OLED display, the Condor delivers superior image quality and detail recognition.
• Advanced Image Processing: Featuring Image Pro technology for enhanced detail recognition and Zoom Pro for digital zooming without loss of picture quality.
• Long Battery Life: The replaceable and rechargeable Li-ion battery offers up to 4.5 hours of continuous operation, ensuring extended usage during outdoor activities.

Ideal for Various Applications:

• Forest hunting
• Birdwatching
• Animal searching
• Adventuring
• Search and rescue operations

Experience powerful imaging capabilities and long-range accuracy with the HIKMICRO Condor LRF thermal monocular. Its advanced features and rugged design make it the perfect companion for outdoor enthusiasts and professionals alike.



Specification

Thermal Module
Image Sensor	VOx Uncooled Focal Plane Arrays
Max. Resolution	384 × 288
Frame Rate	50 Hz
Pixel Interval	12 ?m
Response Waveband	8 ?m to 14 ?m
NETD	Less than 20 mK (@25°C), F# = 1.0
Lens (Focal Length)	25 mm, f1.0
Focus Mode	Focus Ring
Detection Range	1800 m
Min. Focusing Distance	3.5 m
Magnification	2.5× to 20× (8×)
Image Display
Display	1024 × 768, 0.39 inch, OLED
Palettes	Black Hot, White Hot, Red Hot, Fusion
FFC (Flat Field Correction) Mode	Auto, Manual, External Correction
Exit Pupil	4 mm
Eye Relief	15 mm
Diopter (Range)	-5 D to +3 D
Brightness Adjustment	Yes
Tone Adjustment	Cold, Warm
Contrast Adjustment	Yes
Image Pro	Yes
Zoom Pro	Yes
System
Record Video	Yes
Capture Snapshot	Yes
Audio Recording	Yes
Standby Mode	Yes
Storage	Yes
PIP	Yes
Hotspot	Yes
Hot Track	Yes
Distance Measurement	Yes
Power Supply
Battery Type	Replaceable and Rechargeable Li-ion Battery
Battery Operating Time	4.5-hour continuous running with CVBS and hotspot function off (@25°C)
Type-C Power Supply	5 VDC, 2 A Supports External Power Supply
General
Protection Level	IP67
Dimension	184.9 mm × 53 mm × 87.8 mm (7.28" × 2.09" × 3.46")
Weight	400 g without battery
Working Temperature	-30°C to +55°C
Laser Rangefinder
Safety Class for Laser	Class 1
Wavelength	905 nm
Max. Measuring Range	1000 m
Measurement Accuracy	± 1 m
Min. Measuring Range	10 m
